Digi XBee® SX 900 MHz RF modules are the "muscle modules" of the Digi XBee ecosystem, providing a combination of reliability and redundancy for OEMs building low-power, mission-critical wireless devices. They utilize the DigiMesh® networking protocol, featuring redundant mesh network operation and support for low-power sleeping nodes. Customers that don’t require mesh network architecture can configure the Digi XBee 900 SX to operate in simple point to multipoint mode.


XB9X-DMUS-001

Frequency Range
  • ISM 902 to 928 MHz

Transmit Power(Software Selectable)
  • Up to 13 dBm

RF Data Rate
  • Low data rate: 10 kb/s; Middle data rate: 110 kb/s; High data rate: 250 kb/s

Rural Range Line Of Sight
  • Low data rate:Up to 14.5km(9mi)

Dimensions
  • 3.38 x 2.21 x 1.29 cm (1.33 x 0.87 x 0.12 in)

Host Interface Connector
  • 37 castellated SMT pads

Operating Temperature
  • -40° C to 85° C (-40° F to 185° F)

Supply Voltage
  • 2.4 to 3.6 VDC, 3.3 V typical
